1/2.8 CMOS, 1920 × 1080 @ 30FPS
Sensitivity: 0.002 Lux/F1.6, 30 IRE, 0 Lux IR on
Fixed lens 2.8mm (107° )
True Day / Night with ICR Filter, Visible white LED up to 60 m
BLC / HLC / True WDR 130 dB, 3D DNR
Built-in microphone
Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Eyeball design, metal core, IP67, outdoor/indoor use, -40° C~+60° C
Power 12 VDC, 5.1 W max
- Camera design
- Eyeball
- Category Code
- HSC
- Description
- 1/2.8 CMOS, 1920 × 1080 @ 30FPS
Sensitivity: 0.002 Lux/F1.6, 30 IRE, 0 Lux IR on
Fixed lens 2.8mm (107° )
True Day / Night with ICR Filter, Visible white LED up to 60 m
BLC / HLC / True WDR 130 dB, 3D DNR
Built-in microphone
Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Eyeball design, metal core, IP67, outdoor/indoor use, -40° C~+60° C
Power 12 VDC, 5.1 W max - Effective pixels
- 1920(H)×1080(V)
- Electronic Shutter Speed
- PAL: 1/25s–1/100000s NTSC: 1/30s–1/100000s
- Environment
- Outdoor
- Focal length
- 2.8 - 3.5mm
- Focal Length
- 2.8mm
- IR Illumination
- Yes
- Lens Mount
- M12
- Microphone
- Built-in
- Min. Illumination
- 0.02 Lux
- Net camera resolution
- 2 - 4MP
- Network Camera Type
- Fixed Dome/HDTV/Megapixel/Outdoor
- Pixel Resolution
- 2 Mega Pixel
- Power consumption
- 5.1 Watts
- Power options
- 12V
- Power supply requirements
- 12V ±30% DC
- Sensor size
- 1/2.8 CMOS
- Shipping Box Depth
- 15 cm
- Shipping Box Height
- 13.5 cm
- Shipping box quantity
- 1
- Shipping Box Weight
- 0.62 kg
- Shipping Box Width
- 14 cm
- Unit Box Height
- 0.135
- Unit Box Length
- 0.15
- Unit Box Width
- 0.14
- Unit Brutto Volume
- 0.002835 cubm
- Unit Gross Weight
- 0.62 kg
- Unit Net Weight
- 0.17 kg
- Vendor Homepage
- www.dahuasecurity.com/products/All-Products/HDCVI-Cameras/Lite-Series/1080P/1080-P/HAC-HDW1200TRQ(-A)
